Hoshizaki FM-1200AKE-N Nugget Ice Maker – 860kg/24hr

PURE & COOL HIGH-CAPACITY NUGGET ICE MAKER

The Hoshizaki FM-1200AKE-N is a modular nugget ice maker designed for heavy-duty commercial applications such as seafood displays, beverage service, supermarkets, and healthcare. Nugget ice offers soft, chewable texture and helps prevent “freeze burn” on displayed produce or fish.

Its auger-driven ice making system ensures that water consumption is equal to ice output, making it highly efficient. Designed for hygiene and reliability, the unit features carbon auger bearings for durability and reduced maintenance, a self-cleaning flush function, and a diagnostic control panel to assist with operation and service.

Key Features:

Ultra-efficient nugget ice production – up to 860kg/day

Water usage matches ice output (no wastage)

Carbon bearings for longer life and reduced service

Automatic flush system keeps internals clean

Built-in diagnostics for maintenance ease

2-year parts & labour warranty; 5-year compressor (parts only)

Ice Production Capacity:
– Approx. 860kg @ 10°C Air / 10°C Water
– Approx. 730kg @ 21°C Air / 15°C Water
– Approx. 590kg @ 32°C Air / 21°C Water

Compatible Ice Storage Bins:
– 91000025, 91000026, 91000027
– 91000053, 91000054

Cooling System: Air-cooled
Refrigerant: R404A

Electrical: 1 PHASE 220–240V 50Hz / 15 AMP Plug
Amperage: Running: 12.3A / Starting: 76A
Voltage Range: Rated Voltage ±10%

Operating Conditions:
– Ambient Temp: 5–40°C
– Water Temp: 5–35°C
– Water Pressure: 0.05–0.8MPa (0.5–8 bar)

Dimensions:
– Width: 762mm
– Depth: 700mm
– Height: 780mm

Net Weight: 146kg / Packed Weight: 156kg
