ICE MAKER CRESCENT KM-80C-HC

Hoshizaki KM-80C-HC Crescent Edge Ice Maker – 75kg/24hr

The Hoshizaki KM-80C-HC is a self-contained Crescent Edge ice maker capable of producing up to 75kg of high-quality ice per 24 hours. Designed to meet the highest hygiene standards, it is perfectly suited for demanding commercial kitchens and varied operational environments.

Part of the innovative KM Edge range, this model features an enlarged, bonded evaporator surface to accelerate ice harvest cycles, allowing you to produce more ice in less time and instantly increase your serving capacity.

Key Features:

Ice Production Capacity:
– Approx. 68kg/24hr @ 21°C air / 15°C water
– Approx. 55kg/24hr @ 32°C air / 21°C water

Storage Bin Capacity: Approx. 34kg

Freeze Cycle Time: Approx. 23 minutes

Ice Output per Cycle: Approx. 1.15kg / 130 pieces

Cooling System: Air-cooled

Refrigerant: R290 / 147g

Electrical: 220–240V, 50Hz, 1 Phase / 10 Amp Plug

Amperage: Running: 2.1A / Starting: 12.5A

Operating Conditions:
– Ambient Temp: 7–38°C
– Water Temp: 7–32°C
– Water Pressure: 0.07–0.8MPa (0.7–8 bar)

Voltage Range: Rated Voltage ±6%

Dimensions:
– Width: 605mm
– Depth: 712mm
– Height: 842mm with hex bolt legs / 988mm with 150mm adjustable legs

Net Weight: 50kg / Packed Weight: 63kg

Optional Accessories:

87000104 Low Capacity Water Filter System

87000106 320mm Replacement Cartridge

87000148 Water Filter Kit & Gauge

87000146 Water Filter

81000116 Stainless Steel Hose

95001013 Adjustable Leg
