ICE MAKER CRESCENT KM-140C-HC

Hoshizaki KM-140C-HC Crescent Edge Ice Maker – 130kg/24hr

The Hoshizaki KM-140C-HC is a powerful, self-contained Crescent Edge ice maker producing up to 130kg of high-quality ice per 24 hours. Designed to meet the strictest hygiene standards, this unit is suitable for all commercial kitchen configurations and operational demands.

As part of the KM Edge series, it features an enlarged, bonded evaporator surface that enhances the speed of ice production. With shorter harvest cycles, it delivers more ice in less time, helping you serve faster and more efficiently.

Key Features:

Ice Production Capacity:
– Approx. 138kg/24hr @ 10°C air / 10°C water
– Approx. 130kg/24hr @ 21°C air / 15°C water
– Approx. 115kg/24hr @ 32°C air / 21°C water

Storage Bin Capacity: Approx. 55kg

Freeze Cycle Time: Approx. 21 minutes

Ice Output per Cycle: Approx. 1.87kg / 208 pieces

Cooling System: Air-cooled

Refrigerant: R290 / 110g

Electrical: 220–240V, 50Hz, 1 Phase / 10 Amp Plug

Amperage: Running: 3.9A / Starting: 18.6A

Operating Conditions:
– Ambient Temp: 7–38°C
– Water Temp: 7–32°C
– Water Pressure: 0.07–0.8MPa (0.7–8 bar)

Voltage Range: Rated Voltage ±6%

Dimensions:
– Width: 630mm
– Depth: 719mm
– Height: 1,333mm

Net Weight: 69kg / Packed Weight: 81kg

Optional Accessories:

87000105 High Capacity Water Filter System

87000107 450mm Replacement Cartridge

87000149 Water Filter System & Gauge

81000116 Stainless Steel Hose

95001013 Adjustable Leg
